PH-100S - pH / ORP Transmitter

About PH-100S - pH / ORP Transmitter

Electronet series PH-100S are PH / ORP Transmitters used for various industrial applications.

It can accept input from pH / ORP electrode and pH / ORP signal is transmitted in the form of electrical 4 - 20 mA signal. The on-line pH / ORP indication is provided through LCD. Span / Zero adjustments are easily accessibly. These transmitters are suitable for any make of electrode.

Specification

• Display Type: LCD Display
• Accuracy: +/- 0.05 pH / +/-3mV
• Power Supply: 24 V DC, External
• Mounting Type: 2 inch Pipe Mounting
• Dimension: 155 mm (H) x 105 mm (W) X 130 mm (D)
• Calibration Range: 0 to 14 pH / +/-2000mV
• Calibration Method: 3 Point buffer(For pH Only)
• Stability: 0.02pH per 24 Hours, Non- Cumulative
